    Sentry Glass PLus

    DuPont™ SentryGlas® Plus creates new glazing opportunities by changing the way glass performs and providing new design options for architects and building designers.

    Tests have proven that SentryGlas® Plus has exceptional residual strength, even when both lites of glass are broken.

    Code Compliance:

    GB/T 11944  ASTM C1172  EN1279  JIS R3205  AS/NZS4666

    Send Inquiry

    DuPont™ SentryGlas® Plus creates new glazing opportunities by changing the way glass performs and providing new design options for architects and building designers. Tests have proven that SentryGlas® Plus has exceptional residual strength, even when both lites of glass are broken (above photo). This brings greater peace of mind to building owners and occupants in locations that experience typhoons or hurricanes and makes it possible to specify safer laminated glass for point-supported glazing systems, canopies, skylights and railings.

    SentryGlas® Plus is an ideal product for complex glazing projects that require increased strength and enhanced appearance. The benefits of SentryGlas® Plus are not only confined to complex projects. Glazing systems that utilize SGP are typically lighter than their PVB counterparts.

    This can result in larger panels, reduced number of support fittings and a lighter weight support structure that enhance the visual impact.

    There are significant performance benefits that can be achieved when specifying SentryGlas® Plus laminated products from Wallkingdon Glass.

    sentry glass plus

    Exposed Edges - SentryGlas® outperforms conventional PVB in edge stability testing, making it the ideal choice for exposed exterior edges (canopies, railing glass and point supported walls). With SentryGlas® Plus, edge stability numbers (ESNs) continue to be zero at all known installations, including 7-year test panels exposed to severe heat and humidity.

    SentryGlas® Plus is 100 times stiffer and 5 times stronger than traditional interlayers, allowing for thinner make ups with equal or greater strength. In stairs, flooring and overhead glazing, laminated glass made with SentryGlas® Plus performs like engineering materials, with outstanding post-breakage resistance to creep and collapse (far left photo).

    Security - SentryGlas® Plus provides prolonged physical attack and burglary resistance with 5 times the tear strength and 100 times the rigidity of conventional PVB Interlayer's. SGP provides greater security from a range of threats than any other traditional laminated glass.

    sentry glass Plus

    Hurricane-Resistance – Because SentryGlas® Plus is stiffer and harder to tear than conventional laminate interlayer's it can withstand greater impacts. In post-breakage wind cycle testing, hurricane glass made with SentryGlas® Plus lasts longer and maintains building protection long after alternative laminated safety glass has failed.

    SentryGlas® Plus is available in both a UV transmitting option and as a traditional UV blocking interlayer. Unlike most laminate interlayer technologies, DuPont™ SentryGlas® requires no UV protection for lasting strength and clarity. Therefore, SentryGlas® can be made in a specialty, high-UV transmittance sheet, extremely useful when designing controlled environments for many life species (plants, insects, fish, and reptiles).

    Clarity - SentryGlas® Plus structural interlayers are significantly clearer than traditional PVB interlayer's. By combining low-iron glass and SentryGlas® Plus interlayers architects and designers can achieve a laminated glass product with near invisibility. SentryGlas® Plus not only starts clear, it stays clear with a yellowness Index (YI) starting at 1.5 (versus 6 to 12 for conventional interlayer's) and SentryGlas® Plus keeps it's clarity after years of service.

    As the China SentryGlas glass supplier, Wallkingdon glass has become the leading company in China glass industry.

    Code Compliance: GB/T 11944  ASTM C1172  EN1279  JIS R3205  AS/NZS4666


    Hot Tags: Sentry Glass PLus, manufacturers, suppliers, factory, Customized

    Code Compliance: GB/T 11944  ASTM C1172  EN1279  JIS R3205  AS/NZS4666
